Datenblatt: Inconel® 617

Inconel® 617

Ähnliche Hochtemperaturbeständigkeit wie INCONEL® 600/601 mit verbesserter Festigkeit bei vergleichbarer Korrosionsbeständigkeit wie INCONEL® 625.

Erhältlich in allen Profiloptionen

Inconel® 617 - Alloy Wire International 1

Haupteigenschaften

Inconel® 617 offers the following key features:

Ähnliche Hochtemperaturbeständigkeit wie INCONEL® 600/601 mit verbesserter Festigkeit bei vergleichbarer Korrosionsbeständigkeit wie INCONEL® 625.

Typische Anwendungen

Inconel® 617 is known to be suitable for the following applications:

Luftfahrtkomponenten
Landgestützte Gasturbinen
Stromerzeugung
Lebensmittelverarbeitung/a>
Chemische Verarbeitung
Federn


Bezeichnungen

UNS N06617
Wkst. Nr. 2.4663
NiCr22Co12Mo9

Spezifikationen

ASTM B166
ASTM B168
AMS 5887
AMS 5889
ISO 9724
ISO 6208
DIN EN 17753

Chemische Zusammensetzung

The chemical composition of Inconel® 617 is indicated in the table below:

ElementMin %Max %
Ni44.5
Cr2024.00
Co1015
Mo810
Al0.81.50
C0.050.15
Fe3
Mn1
Si1.00
S0.015
Ti0.6
Cu0.5
B 0,006

Legierungsdetails

Inconel® 617 density, melting point, coefficient of expansion, modulus of rigidity, and elasticity is indicated in the table below:

DichteSchmelzpunktAusdehnungskoeffizientSteifigkeitsmodulElastizitätsmodul
8,36g/cm³1330 – 1380 °C11,6 μm/m °C (20 – 100 °C)81 kN/mm²212,0 kN/mm²
0,302 lb/in³2430 – 2510 °F7,0 x 10-6 in/in °F (70 – 212 °F)11,8 ksi30700 ksi

Eigenschaften

The typical mechanical properties of Inconel® 617:

Glühen
Ungefähre Zugfestigkeit<1000 N/mm²<145 ksi
Ca. Betriebstemperatur je nach Belastung** und Umgebung bis zu 1100 °Cbis zu 2012 °F
Federhart
Ungefähre Zugfestigkeit1300 – 1600 N/mm²190 – 230 ksi
Ca. Betriebstemperatur je nach Belastung** und Umgebung Kontaktieren Sie die technische Abteilung von Alloy Wire

Die obigen Zugfestigkeitsbereiche sind typisch. Wenn Sie andere benötigen, fragen Sie bitte.

*Handelsname der Special Metals Group of Companies

**Statische Anwendung = Still/Fixiert/Bewegungslos/Starr
